Garbage copressing truck
Garbage copressing truck
XZJ5080ZYSB5
REQUEST A QUOTE
- FEATURES
- PARAMETERS
| Item | unit | parameter |
| Vehicle parameters | - | BJ5089XXY-FA |
| Chassis models | ||
| Engine type | - | ISF3.8s5141 |
| tonnage | (T) | 3 |
| Length | (mm) | 6370（Great device），6755（Rolling barrel ），6635（bucket） |
| Wideth | (mm) | 2040 |
| Height | (mm) | 2410 |
| Approach Angle/Angle of departure | (°) | 21/12 |
| Maximum weight | (kg) | 8280 |
| Vehicle servicing weight | (kg) | 5150（Great device），5410（Rolling barrel bucket） |
| Rated load | (kg) | 2935（Great device），2675（Rolling barrel bucket） |
| Carriage Volume | (m³) | 6 |
| Fill in the feeder volume | (m³) | 1.1 |
| Drain tank capacity | (L) | 200 |
| Deputy drain tank capacity | (L) | 85 |
| Bucket Capacity | (L) | 643 |
| ground clearance | (mm) | 990 |
| Wideth | (mm) | 1430 |
| Height | (mm) | 780 |
| The cycle time of loading | (s) | 14～16 |
| The tailgate ascending Angle | (°) | ～95° |
| Rated hydraulic pressure | (MPa) | 16.2 |
| Discharging time | (s) | ≤25 |
| The double barrel dumping Angle | (°) | ≥45° |
| Loader lift time | (s) | 13 |
| Max.shift force | (kN) | 103 |
| Max.broken compressive force | (kN) | 91 |
| Compression ratio | - | 1:3 |
| Living garbage compression density | (T/m³) | 0.7~0.8 |
