Articulated boom aerial working platform

/Products/Aerial Working/Articulated boom aerial working platform

Articulated boom aerial working platform

CM5054JGKB

REQUEST A QUOTE

You have choose: Articulated boom aerial working platform - CM5054JGKB

See the verification code Click refresh!

BROCHURE DOWNLOAD|SALES NETWORK

  • FEATURES
  • PARAMETERS
CM5054JGKB

Main Feature：
● Electro-hydraulic proportional control, stepless throttle
● Control box at both turret and platform
● With a 2-section telescopic boom crane
● Limit switch and alarm
● Large outrigger span, outrigger can be operate individually
● Emergency descent power。
● Safety interlock

Model

XHZ5054JGKB

Chassis Model

NKR77LLLWCJAY

Platform Safe Work Load

200kg

Max. Work Height

14.3m

Max. Work Range

6.3m

Dimension

7170×1942×2858 mm

Crane Max. Lift Weight

990kg /1300kg(optional)

Crane Max. Lift Height

9.0 m
