● Shangchai SC8D143G2B1 turbocharged engine features strong power, high efficiency and energy-saving, and high torque reserve coefficient, with the rated power up to 95.5kW.

● The high reliability power shift transmission and the two-stage final drive with spur gear reducing structure features reliable and stable power transmission, high durability, and high operating efficiency.

● The large gilled tube radiator is adopted to effectively guarantee the normal running under high environmental temperature and ease the cleaning.

● The multi-stage filtration system is adopted to effectively guarantee the oil cleanliness and reduce the malfunction rate of hydraulic system.

● The full box-type main frame features high carrying capacity against impact load and bending moment and the high quality welds guarantee the life cycle of the main frame.

● The chassis system features high durability and stability and good traction performance.

● The cab, operating devices, and instrument assembly features high comfort and convenience.

● The trimming blade capable of large-angle forward and backward tilting adopts symmetrically arc-shaped double-faced structure to adapt to double-faced operations.The internally arranged vertical plate weldments guarantee the strength for all trimming blade parts to collect more handled material at one time and adapt to various complicated working environments.

● The two side beams and the crossbeam for the H-shaped blade holder are welded from square steel tubes and the front and rear of crossbeam are welded from integral

angle blocks to guarantee the high strength of blade holder.
