Diaphragm wall grab

Diaphragm wall grab

XDZ150/65-3

REQUEST A QUOTE

You have choose: Diaphragm wall grab - XDZ150/65-3

See the verification code Click refresh!

BROCHURE DOWNLOAD|SALES NETWORK

  • FEATURES
  • PARAMETERS
XDZ150/65-3

1. Mature transducer controlled drive is electromotor start and protected makes the machine stably load. No electric and mechanical impact to electrified wire netting and drilling pipe equipment during starting, working and parking.

2. Two or three constant power motor driving power unit can achieve strong torque and overload capacity through high strength, stable and intense epicyclic gearbox as well as main drive gear box.

3. Specially designed multiple seal structure effectively solve the problem of mud leakage, reduce maintenance consumption and prolong service life.

4. Specially designed impact resistant drilling pipes; pipes joints is intelligently manufactured which can be connected and disconnected easily, makes pipe connecting easy especially for deep drills. Huge middle axis is available for choice.

5. Advanced drilling tools. Specially designed hard alloy cutting bit ensures high drilling efficiency and durability.

6. Automatic testing electrical system offers easy failure investigation.


Project
Working parameter
Drilling diameter
Drill pipe center distance
Max. drilling depth
Main data
Rated speed
Rated torque
Power parameter
Rated power
Drill pipe parameter
Drill pipe diameter
Drill pipe length of basic
Drill pipe condition
Assembly parameter
Center distance
Guide rail center distance
Number of pulley
Diameter of wire rope
Operation mode
Weight parameter
Overall weight
Unit
(mm)
(mm)
(m)
(r/min)
(kN.m)
(kW)
(mm)
(m)
-
(mm)
(mm)
-
(mm)
-
(t)
Parameter
Φ650×3
480×480
30
18.2
26
150(75×2)
Φ219
3、5、8
Hexagon、Bolt
900
600×Φ120
6
Φ22
Electric control
30
