CABIN

A7-W standard cabin,
Four-point full floating   air suspension shock absorber transverse stabilizer, single berth, air suspension driver’s seat, up/down                    and front/back adjustable steering wheel, BEHR  European style new integral A/C heater, VDO  instrument, CAN bus and electrics control system, safety belt with double locking mechanism, power  window and rearview mirror, three locks combined in one, exterior sun visor, top wind deflector side air deflector, electronic hand throttle.

ENGINE:

MODEL

CNHTC D12.34

Rated power

249kw/2000rpm

Max. torque

1490Nm/ 1200-1500rpm

Displacement

9.726L

Type

Inline 6 cylinder, supercharged intercooling,  central supercharger, electronic high pressure and  common rail

Clutch

430 diaphragm spring clutch, hydraulic control air power assisted.

Transmission

SINOTRUK HW15710 10 speeds transmission, main and  auxiliary transmission structure, main transmission  with double countershaft, auxiliary transmission with planetary reducer.

Steering system

German ZF Power assistant steering system

Front axle

HF9  Rated load 9Ton, disc-type or drum type

Rear axle

AC16

Suspension

Front and rear leaf spring suspension, front  suspension with shock absorber, transverse stabilizer , rear suspension is disconnected type  with transverse stabilizer

Brake system:

Service brake: dual-circuit air pressure brake;
                   Parking brake: energy storage spring air cutoff  brake Auxiliary brake: EVB engine extinguish  exhaust brake,

Electric system:

CAN bus control, voltage: 24V,  generator: 2240w;  starter: 7.5kw; battery: 12V/165Ah; 2 pieces

Tyre:

12.00R20

Kerb weight

12270kg

Vehicle overall dimension

8265x2496x3490mm

Carriage internal dimension

5400x2300x1200mm (1300mm, 1400mm, 1500mm )

Lifting way

Middle lift or front lift

Steel thickness of carriage

Floor 8mm x side 4mm

Wheel base

3625 1350mm

color

White, red, gray, yellow, blue, green

Fuel tanker capacity

300L
