Wheel loader

ZL50GV

REQUEST A QUOTE

You have choose: Wheel loader - ZL50GV

See the verification code Click refresh!

BROCHURE DOWNLOAD|SALES NETWORK

  • FEATURES
  • PARAMETERS
ZL50GV





DescriptionSpecificationUnit
Rated operating load5000kg
Bucket capacity2.5 ~ 5.0
Machine weight17300±300kg
Dump clearance at maximum lift3100-3780mm
Reach at maximum lift1100-1220mm
Wheel base3300mm
Tread2250mm
Max.breakout force175±5kN
Max.horse power160±5kN
Hydraulic cycle time-raise<6s
Total hydraulic cycle time<10.5s
Min. turning radius over tyres5925±50mm
Articulation angle38°
Gradeability30°
Tyre size23.5-25-16PR
Overall machine dimension Lx   WxH8225x3016x3515mm
ModelWP10G220E343
Rated Power/Speed162/2000kW/rpm
